IPSEC -IKE Phase 2

IKE Phase 2

• Once IPSec Phase 1 is completed, we move on to Phase 2.
• IPSec Phase 2 is for transferring of data.
• By default there is no encryption or authentication in IPSec phase 2.
• For security in Phase 2, there are 2 IPSec protocols,
• AH-(Authentication-Header )
• ESP-(Encapsulating Security Payload)
• AH and ESP both offer authentication and integrity but ESP only supports Encryption

IPSec Protocols Modes
Both AH and ESP has two modes:

• Transport - We use same original Ip header
• Tunnel - We use new IP Header

IP Header:

IKE Phase 2 Configuration:
        Router-1(config)#crypto ipsec transform-set <Name> esp-aes esp-md5-hmac
        Router-1(config)#
        Router-1(config)#crypto ipsec profile <Name>
        Router-1#(ipsec-profile)set transform-set <Name>

First, We are creating a Transform-set with IPSec Protocol ESP (Encryption : aes , Authentication : md5)
Then, we need to create crypto map or crypto ipsec profile and map the transform-set.

• IP NATTING is done, you need to give an exception for the concerned packets (Eg: ACL), or else the packets will not be pass via IPSec in a secured manner (For Policy based VPN - IPSec)
• No need of NATTING exception in Route Based (GRE).

You can also watch my Video Tutorial:

That's it.
